The project for the modernization of the Salerno-Reggio Calabria concerns the construction of a new route with total length of 443 km. The project is divided into 62 actions (12 macro-lots, 44 individual lots, 6 interchanges).
Piacentini Ingegneri was involved in the design of modernization and compliance to standards C.N.R. of the existing road, the area with very arduous mountain involves the design of bridges, tunnels and important works of support, upstream and downstream of the highway.
MACRO-LOT 0
• Maximum design speed 120 km / h.
• Carriageway Type 1 / A – Highway (in agreement with the CNR/80).
• Section with separated carriageway: 3+3 lanes plus an emergency lane in each direction; total width of 25.00 m.
Detailed executive planning and technical site support
• viaduct Farneta
• viaduct Tanagro:
• total length 462 m south and 422 m north
• deck with mixed steel concrete with continuous beam, n. of beams 2+2 and a height from 2.88 m to 5 m,
• n.7 spans of maximum light equal to 90 m, stacks of 30 m height.
MACRO-LOT 4b
• Highway length equal to 18.2 km
• Maximum design speed 120 km / h.
• Carriageway type 1 / A – Highway (in agreement with the CNR / 80).
• Section with separated carriageway 2+2 lanes plus an emergency lane in each
direction; Total width of 25.00 m.
Final design and technical site support
Highway track, San Mango and Falerna interchanges
• 39 viaducts
• 9 overpass
• 1 gallery
• 82 support structures including 19 retaining walls of reinforced concrete,
• 26 bulkheads in piles, earth reinforced walls 26, 11 interventions in soil nailing
• 33 hydraulic structures and environmental mitigation works
Final design and technical site support of the Fiume Grande Viaduct – Technical data
• Total length 342 m
• Deck in mixed steel concrete with continuous beams, n. of beams 2+2 and a height of 4.60 m
• n.4 spans with maximum light equal to 95 m
• Stacks of 37.60 m height
Salerno Cosenza, Italy
City, Country
ANAS S.p.A.
Client
2008/2013 – Work in progress
Date
